TIA-942-C compliance by tier and facility type

Tick what the facility has against ANSI/TIA-942-C (2024) across site and architecture, electrical, mechanical, telecommunications, fire protection and physical security. The items shown follow the tier and facility type you pick; each item weighs W1 to W3 and each category by its share of risk. Scored in your browser.

basis ANSI/TIA-942-C (2024) · 56 items for this tier and facility type · facility Enterprise · updated 2026-10

DC Solutions → Checklist → TIA-942

Tier level
Facility type
Checklist
Tick what the facility has. W3 critical, W2 important, W1 standard.

Results

score = Σ category % · weight / Σ weights

Headline

Overall compliance
0%
F — Incomplete

Detail

Items checked
0
Items applicable
0
Risk index
0
Tier level
3
Weakest category
0%
Maturity
L1
Facility type
Enterprise

Category scores

Top gaps
FIG. 1 Share of weighted items in place · computed from the inputs above
FIG. 2 Score by category against the 75 % target · amber = weakest · computed from the inputs above

Full analysis — tier radar, Monte Carlo range, gap analysis, score by tier, remediation roadmap and sensitivity

FIG. 3 Score by category for each tier · amber = selected tier · computed from the inputs above
FIG. 4 Compliance score over 10,000 runs · amber = median bin · computed from the inputs above

Gap analysis · unchecked items by priority

PriorityItemCategoryWeightReference

Monte Carlo range

The spread of the compliance score when each item's weight is varied.

Uncertainty: computing…

Score by tier

Remediation roadmap · first 15 gaps

ItemEffortEst. CostTimelineImpact

Sensitivity · the ten items that move the score most

02 / Reference

Method

  • Category scoreΣ w (checked) / Σ w (applicable) · 100, w = 1 to 3
  • OverallΣ (category score · category weight) / Σ category weights
  • Category weightelectrical 1.5, mechanical 1.3, fire 1.1, site 1.0, telecom 1.0, security 0.9
  • Risk indexoverall · (1 − min(0.15, σ of category scores / 200))
  • MaturityL2 at risk index ≥ 40, L3 ≥ 60, L4 ≥ 80, L5 ≥ 95
  • GradeA+ ≥ 95, A ≥ 85, B ≥ 75, C ≥ 65, D ≥ 50, else F
  • Monte Carlo10,000 runs, each item weight · U(0.85, 1.15)

Computed against

ANSI/TIA-942-C (2024)Uptime Institute Tier ClassificationANSI/BICSI 002-2024clause numbers follow TIA-942-B and are indicative
